TIMCO Grade 13 Fire Door Hinges Polished Stainless Steel 101 x 76 x 3 mm – 3 Pack
TIMco
Product Code: 334444
For heavy-duty doors in public buildings, including compatible fire-door assemblies.
Key features
- Size: 101 x 76 x 3 mm.
- Lubricated ball-bearing action for smooth operation.
- Stainless steel construction.
- Fixing screws included.
- Pack quantity: 3 hinges.
Product details
Finish: Polished Stainless Steel.
Suitable for 30- and 60-minute fire doors, subject to the door assembly specification.
Door-weight rating stated: up to 120 kg.
Tested to 200,000 cycles.
Installation notes
Fit with the specified intumescent hinge pads when installing on fire doors. Pads are not included; product code 487385.
Specifications
| BS EN Classification | 476114013 |
| Carton Qty (packs) | 20 |
| CE Standard | BS EN 1935:2002 |
| Certifire Number | CF714 |
| Corner Type | Square |
| Corrosion Rating (1-5) | 3 - Urban & industrial areas with a low salt atmosphere |
| Finish | Polished Stainless Steel |
| Fire Rating | 30 & 60 Minutes |
| Grade | 13 |
| Knuckle Type | Ball Bearing |
| Length x Width (mm) | 101 x 76 |
| Material | Stainless Steel |
| No. Of CSK Screws | 24 |
| Pack Dimensions L x W x H (mm) | 152 x 64 x 34 |
| Pack Qty | 3 |
| Pack Weight (kg) | 0.84 |
| Rec. Screw Gauge (imp.) | 10 |
| Rec. Screw Ø (mm) | 5 |
| Screw Size (imp.) | 10 x 1 1/4 |
| Screw Size (mm) | 5.0 x 30 |
| Thickness (mm) | 3 |
Product code: '334444
